| MOQ: | 100KGS |
| Price: | USD 20-25/KG |
| Standard Packaging: | Wooden Box |
| Delivery Period: | 7 Days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 50000KGS |
EN 1.4529 stainless steel is a superaustenitic (highly alloyed) stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the solution annealed (AT) condition. 1.4529 is the EN numeric designation for this material. X1NiCrMoCuN25-20-7 is the EN chemical designation.
It has a moderately high tensile strength and a moderately high ductility among wrought superaustenitic stainless steels.
The graph bars on the material properties cards below compare EN 1.4529 stainless steel to: wrought superaustenitic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
| tandards | Steel Grades | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Chemical Composition % | ||||||||||
| C: | Mn: | Si: | P: | S: | Cr: | Ni: | Mo: | Cu: | N: | |
| EN | X1NiCrMoCuN25-20-7 - X1CrNiMoCuN25-20-7 - 1.4529 | |||||||||
| <0.02 | <1.0 | <0.5 | <0.03 | <0.01 | 19.0 - 21.0 | 24.0 - 26.0 | 6.0 - 7.0 | 0.5 - 1.5 | 0.10 - 0.25 | |
| ASTM | UNS N08926 - 26-3 Mo - 6 Mo - Alloy 926 | |||||||||
| <0.02 | <2.0 | <0.5 | <0.03 | <0.01 | 19.0 - 21.0 | 24.0 - 26.0 | 6.0 - 7.0 | 0.5 - 1.5 | 0.15 - 0.25 | |
| ASTM | UNS N08925 | |||||||||
| <0.02 | <1.0 | <0.5 | <0.045 | <0.03 | 19.0 - 21.0 | 24.0 - 26.0 | 6.0 - 7.0 | 0.8 - 1.5 | 0.1 - 0.2 | |
| SUS | 317 J5L | |||||||||
| <0.02 | <2.0 | <1.0 | <0.045 | <0.03 | 19.0 - 23.0 | 23.0 - 28.0 | 4.0 - 5.0 | 1.0 - 2.0 | - | |
1.4529 grade is high alloyed stainless steel with an austenitic structure, which can be classified as nickel alloys (according to American standards).
Delivered in the supersaturated state exhibits resistance to intercrystalline, pitting, and stress corrosion, salt, sea water, chloride, sulfuric acid, phosphoric acid and other aggressive chemicals in high concentrations in liquid and gaseous form.
Materials of 1.4529 grade, except high chemical resistance, can work at elevated temperatures while maintaining adequate mechanical properties.
Ignoring the high content of nickel and chromium, the standard also specifies a relatively large amount of Molybdenum and Nitrogen, which is particularly worthwhile when selecting grade from the related group of high alloy steels.
Significantly higher percentages of Nitrogen and Molybdenum contribute to limiting the creation of intermetallic phases, as well as improving the impact resistance.
Steel is used mainly in the chemical, paper, cryogenic, aerospace, and power industries. The main end products are heat exchangers, chemical tanks, pumps, screws, aircraft components, bushings, shafts, water desalination and flue gas desulphurisation equipment, valves and even radiator components.
| Properties | Operating temperature | |||||
|---|---|---|---|---|---|---|
| 100℃ | 200℃ | 300℃ | 400℃ | 500℃ | ||
| Yield point, Rp0,2 | MPa | > 230 | >190 | >170 | >160 | - |
| Linear Expansion Factor, α | * 10-6 K-1 | 15,8 | 16,1 | 16,5 | 16,9 | 17,3 |
| Modulus of elasticity, E | GPa | 190 | 182 | 174 | 166 | 158 |
|
|
