| MOQ: | 100KGS |
| Price: | USD18.45/KG |
| Standard Packaging: | Wooden Box |
| Delivery Period: | 7 Days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 50000KGS |
| Material | Inconel,Hastelloy,Monel,Incoloy,GH,Precision alloy,Stainless steel | |
| Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc | |
| Shape | Sheet ,Coil, Bar,Pipe,Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square | |
| Surface | Mirror,Brushed,Mil Finished,Polished etc | |
| Material Grade | Inconel | Inconel600(N06600 GH3600), Inconel601(N06601 GH3600), Inconel625(N06625 GH3625), InconelX-750(N07750 GH4145), Inconel 718(N07718 GH4169), Inconel690 |
| Hastelloy | Hastelloy B-2,Hastelloy C,Hastelloy C-267(N10276),Hastelloy C-4, Hastelloy C-22(N06022),Hastelloy G30(N06030) |
|
| Monel | Monel 400(N04400),Monel K500(N05500) | |
| Incoloy | Incoloy A-286(GH2132 N662),Incoloy800 800H 800HT,Incoloy725, Incoloy825,Incoloy925,Incoloy926(N08926 1.4529) |
|
| GH | GH2132(N66286 A286 Gr6),GH3625(Inconel625 UNS N0), GH4169(Inconel718 UNS N0),GH3030,GH3039,GH4033,GH3128 |
|
| Precision alloy | 4J36,4J29,1J79 | |
| Stainless steel | Alloy 20(N08020),904L(N08904),254SMo(F44 S31254) | |
| Specification | Sheet | Thickness 0.8-36mm; Width 650-2000mm; Length 800-4500mm |
| Strip | 0.05*5.0-5.0*250mm | |
| Pipe | φ 6-273mm; Thickness 1-30mm; Length 1000-8000mm | |
| Bar | φ4-50mm; Length 2000-5000mm | |
| Wire | 0.01-10mm | |
| Application | It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, and ship components. It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen mesh etc |
|
| Dimension | Range |
| Diameter | 3-480mm |
| Length |
1000mm, 2500mm, 3000mm,3500mm, 4000mm 5000mm 6000mm 10000mm 12000mm, etc or as customer's request |
| % | C | Mn | Si | Gr | S | Ni | Cu | Fe | Ai | Ti | |
| 800 | Min. | - | - | - | 19 | - | 30 | - | Balance | 0. 15 | 0. 15 |
| Max. | 0.10 | 1.5 | 1 | 23 | 0. 015 | 35 | 0.75 | Balance | 0.60 | 0.60 | |
| 800H | Min. | 0. 05 | - | - | 19 | - | 30 | - | Balance | 0. 15 | 0. 15 |
| Max. | 0.10 | 1.5 | 1 | 23 | 0. 015 | 35 | 0.75 | Balance | 0.60 | 0. 6 | |
| 800HT | Min. | 0. 06 | - | - | 19 | - | 30 | - | Balance | 0. 15 | 0. 15 |
| Max. | 0.10 | 1.5 | 1 | 23 | 0. 015 | 35 | 0.75 | Balance | 0.60 | 0.60 |
| Mechanical properties | Tensile, min, ksi[MPa] | Yield, min, ksi[MPa] | Elongation, %(min) |
| Incoloy 800 | 75[517] | 30[207] | 30 |
| Incoloy 800H | 65[448] | 25[172] | 30 |
| Incoloy 800HT | 65[448] | 25[172] | 30 |
| Incoloy 825 | 85[586] | 35[241] | 30 |
800 Heat exchangers and process piping Furnace components Ammonia effluent coolers
800H Chemical and petrochemical processing Pressure vessels Heat exchangers Industrial furnaces
|
|
