| MOQ: | 100KGS |
| Price: | USD4.45/KG |
| Standard Packaging: | Wooden Box |
| Delivery Period: | 7 Days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 50000KGS |
Stainless steel channel steel is a long strip of steel with a groove-shaped cross-section. Same as I-beam, stainless steel channel steel is also divided into ordinary channel steel and light channel steel. The representation method of model and specification is also represented by waist height (h) × leg width (b) × waist thickness (d) in millimeters.
| Item | Stainless Steel Channel |
| Steel grade | 200/300/400 series |
| Standard | ASTM/A213/A312/A269/A778/A789/DIN 17456/DIN17457/DIN 17459/JIS G3459/JIS G3463/GOST9941/EN10216/BS3605/GB13296 |
| Material | 304/304L/309S/310S/316/316Ti/317/317L/321/347/347H/304N/316L/316N/201/202 |
| Surface | Polishing/Annealing/Pickling/Bright |
| Type | Hot rolled and Cold rolled |
| Delivery time | Prompt delievry or as the order quantity. |
| Package | Standard export seaworthy package or as required. |
| Application | Widely used in petroleum,foodstuff,chemical industry,construction,electric power,nuclear,energy,machinery,biotechnology,paper making,shipbuilding,boiler fields.Pipes also can be made according to the customer's required. |
Stainless Steel C Channel, U Channel Steel
| Type | Specifications |
Height (mm) |
Leg width (mm) |
Thickness (mm) |
Theoretical weight (kg/m) |
|
Channel steel / Stainless Steel |
5# | 50 | 37 | 4.5 | 5.438 |
| 6.3# | 63 | 40 | 4.8 | 6.634 | |
| 8# | 80 | 43 | 5 | 8.045 | |
| 10# | 100 | 48 | 5.3 | 10.007 | |
| 12# | 120 | 53 | 5.5 | 12.059 | |
| 12.6# | 126 | 53 | 5.5 | 12.318 | |
| 14#a | 140 | 58 | 6 | 14.535 | |
| 14#b | 140 | 60 | 8 | 16.733 | |
| 16#a | 160 | 63 | 6.5 | 17.24 | |
| 16#b | 160 | 65 | 8.5 | 19.752 | |
| 18#a | 180 | 68 | 7 | 20.174 | |
| 18#b | 180 | 70 | 9 | 23 | |
| 20#a | 200 | 73 | 7 | 22.637 | |
| 20#b | 200 | 75 | 9 | 25.777 | |
| 22#a | 220 | 77 | 7 | 24.999 | |
| 22#b | 220 | 79 | 9 | 28.453 | |
| Channel steel | 25#a | 250 | 78 | 7 | 27.41 |
| 28#a | 280 | 82 | 7.5 | 31.427 | |
| 28#b | 280 | 84 | 9.5 | 35.832 | |
| 30#a | 300 | 85 | 7.5 | 34.463 | |
| 32#a | 320 | 88 | 8 | 38.083 | |
| 32#b | 320 | 90 | 10 | 43.107 |
1. Grade:200 series,300 series,400 series
2. Thickness: 5*37*4.5mm-320*90*10mm
3. Standard: JIS, AISI, GB
4. ISO9001:2008
5. Packing:Standard export packing.
6. Payment terms:T/T L/C
7. Delivery time:15days upon receipt of the deposit.
8.Surface:2B,NO.1,NO.2D,NO.2B,BA,NO.3,NO.4,NO.240,NO.400,Hairline, NO.8,Brushed or
as requested.
9.Applications:construction field ,ships building industry ,petroleum and chemical industries
war and electricity industries ,food processing and medical industry, boiler heat exchanger machinery and hardware fields
A1: How can I get a quotation from you ?
Q1:You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
A2:Can I get samples before order ?
Q2:Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings. We can build the molds and fixtures.
A3:How can you garantee what I got will be good ?
Q3:We are factory with 100% predelivery inspection which garantee the quality.And as golden supplier on Alibaba. Alibaba assurance will make garantee,which means alibaba will pay your money back in advance if there is any problem with the products.
A4:How do you make our business long-term and good relationship?
Q4: We keep good quality and competitive price to ensure our customers benefit ;We respect every customer as our friend and we sincerely do business and make friends with them,? no matter where they come from. Please feel free to leave us message if you have any question about us and our products.
|
|
