| MOQ: | 1 t |
| Price: | Negotiation |
| Standard Packaging: | Seaworthy Package |
| Delivery Period: | 15 work days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 500 t/M |
| Specification | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| Dimension | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Sheets Size Range | Cold rolled Sheet 0.5-6.4 mm, Hot rolled Sheet 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Finish | 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled SA 240 S32304 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| Stock available in form of | SA 240 UNS S32304, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
| Plasma profiles | As per client's specification |
| Tolerances | EN 10258/ DIN 59381 |
| Profiling |
To provide a full profiling service in UAE we use numerous profiling methods including:
|
| Value added services for SA 240 UNS S32304 |
|
| Standards and approvals for SA 240 UNS S32304 |
|
| Why choose us? |
|
| 3/16" | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | 7/8" | 1" | 1 1/8" | 1 1/4" | 1 3/8" | 1 1/2" |
| 4.8mm | 6.3mm | 7.9mm | 9.5mm | 12.7mm | 15.9mm | 19mm | 22.2mm | 25.4mm | 28.6mm | 31.8mm | 34.9mm | 38.1mm |
| 1 5/8" | 1 3/4" | 2" | 2 1/4" | 2 1/2" | 2 3/4" | 3" | 3 1/4" | 3 1/2" | 4" | 5" | 6" | - |
| 41.3mm | 44.5mm | 50.8mm | 57.2mm | 63.5mm | 69.9mm | 76.2mm | 82.6mm | 88.9mm | 101.6mm | 127mm | 152.4mm | - |
| C | Mn | Si | P | S | Cr | Cu | Ni | N |
| 0.03 | 2.5 | 1.0 | 0.04 | 0.03 | 21.5 -24.5 | 0.05-2.0 | 3.0-3.5 | 0.05-2.0 |
| Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (HB) MAX |
| 87 | 58 | 25 | 293 |
| Density at 68°F (20°C) | 0.28 lbm/in3 7800 kg/cm3 |
| Coefficient of Thermal Expansion | ax10-6°C-1 |
| 68°F to: 212°F (20 -100°C) | 13 |
| 68°F to 392°F (20 -200°C) | 13.5 |
| 68°F to 572°F (20 -300°C) | 14 |
| Thermal Conductivity | W.m-1.K-1 |
| at 68°F (20°C) | 17 |
| at 212°F (100°C) | 18 |
| at 392°F (200°C) | 19 |
| at 572°F (300°C) | 20 |
| Electrical Resitivity | (μ_ cm) |
| at 68°F (20°C) | 80 |
| at 212°F (100°C) | 92 |
| at 392°F (200°C) | 100 |
| at 572°F (300°C) | 105 |
| Specific Heat | (Btu/lb/°F) |
| 32°F to: 212°F (20 -100°C) | 0.11 |
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
Stainless Steel,Pre-painted Steel,Galvalume Steel,Galvanized Steel,Carbon Steel
3. why should you buy from us not from other suppliers?
Our advantages : We have at least 12 years producing and R&D experience on steel products and most customized products of all material are accepted . High Quality Products to win the market ; Competitive Price to attract customers ; Excellent Service .
|
|
