| MOQ: | 100KGS |
| Price: | 21.5 USD/KG |
| Standard Packaging: | Export Packing |
| Delivery Period: | 7 Days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 50000KGS |
Alloy 28 (UNS N08028, W. Nr. 1.4563, Sanicro 28) is a nickel-iron-chromium alloy with additions of molybdenum and copper. It has excellent resistance to both reducing and oxidizing acids, to stress-corrosion cracking, and to localise attack such as pitting and crevice corrosion. The alloy is especially resistant to sulphuric and phosphoric acid. Used for chemical processing, pollution control equipment, oil and gas well piping, nuclear fuel reprocessing, acid production and pickling equipment.
▪ Chemical and petrochemical processing industry
▪ Downhole service in deep sour gas wells.
Incoloy 28 Chemical Composition
| Element | Content (%) |
| Iron, Fe | 29-40.4 |
| Nickel, Ni | 30-34 |
| Chromium, Cr | 26-28 |
| Molybdenum, Mo | 3-4 |
| Manganese, Mn | ≤2.5 |
| Others | Remainder |
| Properties | Metric | Imperial |
| Tensile strength(annealed) | 500 MPa | 72.5 ksi |
| Yield strength(annealed) | 214 MPa | 31 ksi |
| Elongation at Break(Cold worked) | 15% | 50% |
| Modulus of Elasticity | 200 GPa | 29000 ksi |
| Hardness, Rockwell B | 80-90 | 80-90 |
| Hardness, Rockwell C | 33 | 33 |
| Incoloy 28 available sizes and specifications | |
| Grade | Incoloy 28 |
| Nickel plate | Thickness: 0.3mm - 150.0mm Width: 1000mm - 3000mm |
| Nickel strip/ nickel foil | Thickness: 0.02mm - 16.0mm Width: 5mm - 3000mm |
| Nickel coil | Thickness: 0.3mm - 16.0mm Width: 1000mm - 3000mm |
| Nickel pipe | Outside diameter: 6mm - 1219mm Thickness: 0.5mm - 100mm |
| Nickel Capillary Pipe | Outside diameter: 0.5mm - 6.0mm Thickness: 0.05mm - 2.0mm |
| Nickel bar | Diameter: Ф4mm - Ф600mm |
| Nickel wire rod | Diameter:Ф0.01mm - Ф6mm |
Q1: Do you accept the trial order ?
A1: Yes,if we have the exactly size in stock.we can delivery even 1 piece/meter .
Q2: Can I have free sample before making orders?
|
|
